Tianma LCD Displays TM070JDHP03-00 7.0 inch 149.76×93.6 mm Active Area 161.2×107.2×4.4 mm Outline

Product Categories
N&S ELECTRONIC CO., LIMITED
Contact Now

Tianma LCD Displays TM070JDHP03-00 7.0 inch 149.76×93.6 mm Active Area 161.2×107.2×4.4 mm Outline

Brand Name : Tianma LCD Displays

Model Number : TM070JDHP03-00

Certification : ISO9001

Place of Origin : Japan,Korea

MOQ : 1 piece

Payment Terms : T/T, Western Union, MoneyGram, Paypal

Supply Ability : 100 PCS PER DAY

Delivery Time : 1-3 Working Days

Packaging Details : Antistatic bag, Bubble Bag, Foam Box and Carton Box.

Panel Type : a-Si TFT-LCD , Panel

Panel Size : 7.0 inch

Resolution : 1280(RGB)×800 , WXGA

Display Mode : SIP, Normally Black, Transmissive

Contrast Ratio : 600:1 (Typ.)

Display Colors : 16.7M (6-bit + Hi-FRC) , CIE1931 65%

Response Time : 35 (Typ.)(Tr+Td)

Viewing Angle : 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D)

Contact Now

Tianma LCD Displays TM070JDHP03-00 7.0 inch 149.76×93.6 mm Active Area 161.2×107.2×4.4 mm Outline

TIANMA TM070JDHP03-00 General Features

Panel Brand :TIANMA
Panel Model :TM070JDHP03-00
Panel Type :a-Si TFT-LCD , Panel
Panel Size :7.0 inch
Resolution :1280(RGB)×800 , WXGA
Display Mode :SIP, Normally Black, Transmissive
Active Area :149.76×93.6 mm
Outline :161.2×107.2×4.4 mm
Surface :Hard coating (3H)
Brightness :400 cd/m² (Typ.)
Contrast Ratio :600:1 (Typ.)
Display Colors :16.7M (6-bit + Hi-FRC) , CIE1931 65%
Response Time :35 (Typ.)(Tr+Td)
Viewing Angle :89/89/89/89 (Typ.)(CR≥10) (L/R/U/D)
Frequency :60Hz
Lamp Type :9S2P WLED
Signal Interface :LVDS (1 ch, 8-bit) , 40 pins
Input Voltage :3.3V (Typ.)


TIANMA TM070JDHP03-00 Optical Features

Display Mode :SIP, Normally Black, Transmissive
Brightness :400 cd/m² (Typ.)
Contrast Ratio :600 : 1 (Typ.) (Transmissive)
Display Color :16.7M (6-bit + Hi-FRC)
Color Gamut :65% NTSC (CIE1931)
Response Time :35 (Typ.)(Tr+Td)
Viewing Angle :89/89/89/89 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :Symmetry
White color Chromaticity :Wx:0.310; Wy:0.320
White Variation :1.25/1.33 (Typ./Max.)(9 points)


We Can Do for You:
1) One-to-one service with efficient& professional support;
2) Protection of your design and all your private information;
3) We could supply hard-to-findLCD screen replacements;
4) Quality stability, can to provide certification of products;
5) Convenient payment methods: PayPal, T/T and Western Union;
6) Speedy shipment: we could arrange the shipment within 1-3 business days.
7) Quality & Service: Our priority has always been providing our clients with great quality products and superior customer service.
8) Unbeatable Prices: Wecontinuously strive to find ways of reducing our production costs, and passing the savings to you.

The reasons you choose us
1).More competitive price! As aprofessional LCD Distributor,we have our own souring lines &solutions to support us for the more competitive service, not only the price, but also the stock for the hard-to-find LCD panels.
2).Great quality! All LCD Screen we sent are with good quality guarantee,100% quality check and full one year warranty!
3).Fast delievery! Delivery time will be faster than others.
4).Great shipping service! We have cooperated with DHL,UPS and EMS for long time,so we could promise save much more money on the shipping cost and betterservice is offered!
5).Best sale-service!Professional team to service with you before sale, on sale & after service.

Below are our other LCD panels stock for your easy reference:

Panel ModelBrandSizeResolution
TM240160XCFWGRATianma2.2"240×160
TM128128F6CCWGWC1Tianma1.44"128×128
TM12864G3CCWGWA-1Tianma2.4"128×64
TM050XYSP02Tianma5.0"540×960
TM050JYHN11-00Tianma5.0"720×1280
TM055JYSP08Tianma5.5"720×1280
TM040XYHP01Tianma4.0"640×1136
TM055JYSP03Tianma5.5"720×1280
TM055JYHP03Tianma5.5"720×1280

We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk
Details Pictures for Tianma LCD Displays TM070JDHP03-00

Tianma LCD Displays TM070JDHP03-00 7.0 inch 149.76×93.6 mm Active Area 161.2×107.2×4.4 mm Outline
