High resolution 1280*768 lcd professional display 12.1 inch LTD121EX1S

Brand Name : Industrial LCD Displays

Model Number : LTD121EX1S

Certification : ISO9001

Place of Origin : Japan/Taiwan

MOQ : 1 piece

Payment Terms : T/T, Western Union,paypal

Supply Ability : 1000 PCS PER DAY

Delivery Time : 1-3 Working Days

Packaging Details : Antistatic bag, Bubble Bag, Foam Box and Carton Box.

Panel Size : 12.1 inch

Resolution : 1280(RGB)×768 , WXGA

Operating Temperature : 0~ 50 °C

Storage Temperature : -20 ~ 60 °C

Brightness : 250cd/m² (Typ.)

Input Voltage : 3.3V (Typ.)

Form Factor : Flat Rectangle Display

Pixel Configuration : RGB Vertical Stripe

Active Area : 263.04×157.824 mm

Outline : 275×173.5×5.2 mm

Contact Now

High resolution 1280*768 lcd professional display 12.1 inch LTD121EX1S

Guarantee:
(1) All items will be strictly tested and shipped with strong package.
(2) We have 3~6months warranty for every item, depend on the different item.
(3) We will do our best to solve any possible problem for your after sale. Please contact with us..

General Features

Panel Brand : Toshiba Matsushita
Panel Model : LTD121EX1S
Panel Type : LTPS TFT-LCD , Panel
Panel Size : 12.1 inch
Resolution : 1280(RGB)×768 , WXGA
Display Mode : TN, Normally White, Transmissive
Active Area : 263.04×157.824 mm
Outline : 275×173.5×5.2 mm
Shape Style : Wedge (PCBA Bent, Depth ≥5.2mm)
Brightness : 250 cd/m² (Typ.)
Contrast Ratio : 600:1 (Typ.)
Display Colors : 262K (6-bit)
Response Time : 50 (Max.)(Tr+Td)
Frequency : 60Hz
Lamp Type : 1 pcs CCFL Without Driver
Signal Interface : LVDS (1 ch, 6-bit) , 20 pins
Input Voltage : 3.3V (Typ.)


Mechanical Features

Panel Size : 12.1 inch
Dot Resolution : 1280(RGB)×768 (WXGA)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 123 PPI
Aspect Ratio : 15:9 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.0685×0.2055 mm (H×V)
Pixel Pitch : 0.2055×0.2055 mm (H×V)
Weight : 250g (Typ.)
Active Area : 263.04×157.824 mm (H×V)
Bezel Area : 267.9×162.9 mm (H×V)
Outline Dimension : 275×173.5 mm (H×V)
Outline Depth : 5.2 (Max.) mm
Shape Style : Wedge (PCBA Bent, Depth ≥5.2mm)
Holes & Brackets : Side mounting holes (4-M2) on left, right bezel
Landscape or Portrait : Landscape type
Touch Panel : Without

Toshiba Matsushita LTD121C30S Optical Features

Display Mode : TN, Normally White, Transmissive
Brightness : 250 cd/m² (Typ.)
Contrast Ratio : 600 : 1 (Typ.) (Transmissive)
Display Color : 262K (6-bit)
Response Time : 50 (Max.)(Tr+Td)

Here comes our other LCD panels stock for your easy reference:

Pls contact to us for more stock information: salespm@nselectronic.com.hk

Panel Model Brand Size Resolution
ED133TT1 E Ink 13.3" 2200×1650
ED060SD1 E Ink 6.0" 600×800
ED060SCT E Ink 6.0" 600×800
ET043OC1 E Ink 4.4" 360×640
EN133UT1 E Ink 13.3" 1600×1200
ED047TC1 E Ink 4.7" 540×960
ED133UT1 E Ink 13.3" 1600×1200
ES133UT1 E Ink 13.3" 1600×1200
ED060SCQ E Ink 6.0" 600×800

Toshiba Matsushita LTD121C30S Backlight System

Lamp Position : Edge light type (Bottom side)
Lamp Type : CCFL
Lamp Amount : 1 pcs
Lamp Shape : Straight
Lamp Voltage : 630V (Typ.)
Lamp Current : 6.0mA (Typ.)
Lamp Startup Voltage : 1500/1800V (Min./Max.)(Ta=0℃)
Interface Type : Connector

[Delivery Time]

The LCD Screen Replacements In stock, ship within 1-3 days.

[Quality Guarantee]

100% New and Original
180-365 Days quality warranty

[Payment Opinions]

1. T/T (Wire Transfer)

2. Western Union

3. Moneygram

4. Paypal

Why Choose our company?

  • Our LCD module can ensure quantity of sale especial for the Hard-to-find LCD screen replacements.
  • Reliability test and full examination to ensure the high quality of the display.
  • Strictly ISO9001 quality management system.
  • Mature and Professional after-sale service.
  • Various cooperation experience with big brands, such as AUO, Chimei, Hitachi, Innolux, KOE, Tianma, LG, NEC, Samsung, Sharp, Optrex and more other TFT LCD Display brands.

High resolution 1280*768 lcd professional display 12.1 inch LTD121EX1S


Product Tags:

industrial touch screen display



industrial lcd panel


Wholesale High resolution 1280*768 lcd professional display 12.1 inch LTD121EX1S from china suppliers

High resolution 1280*768 lcd professional display 12.1 inch LTD121EX1S Images
