5.9" 1080P LS059T1SX01 1080*1920 TFT LCD screen display with HDMI MIPI driver board with MIPI connector for VR product

  • 1
  • 2
  • 3

Brand Name : SHARP LCD Displays

Model Number : LS059T1SX01

Certification : ISO9001

Place of Origin : Japan

MOQ : 10

Price : USD

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram,HKIN ESCROW .....

Supply Ability : 1000

Delivery Time : 1-2days

Packaging Details : Standard packing

Product number : LS059T1SX01

Resolution : 1080×1920

C/R : 1000:1

Brightness : 400

Backlight : WLED

Interface : LVDS

Contact Now

5.9" 1080P LS059T1SX01 1080*1920 TFT LCD screen display with HDMI MIPI driver board with MIPI connector for VR product

SHARP LS059T1SX01 General Features

Panel Brand : SHARP
Panel Model : LS059T1SX01
Panel Type : CG-Silicon , LCM
Panel Size : 5.9 inch
Resolution : 1080(RGB)×1920 , FHD
Display Mode : Normally Black, Transmissive
Active Area : 72.9×129.6 mm
Outline : 76.2×139.1 mm
Surface : Clear
Brightness : 400 cd/m² (Typ.)
Contrast Ratio : 1000:1 (Typ.)
Display Colors : 16.7M (8-bit) , CIE1931 70%
Response Time : TBD
Viewing Angle : 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : 7S2P WLED
Signal Interface : MIPI , 30 pins

SHARP LS059T1SX01 Packing Form

Amount per Box : 120 pcs
Box Size : 580×365×187 mm (L×W×H)
Box Gross Weight : 8.5 Kgs

Company Advantage:

Kyocera offers touch panels for all of our TFT-LCD products, from 3.5" to 12.1". Our touch panel's provide high quality, reliability and durability. Factory installed with a full factory warranty.

Custom touch solutions are also available from our Value Added assembly plant contains but not only for LCD Screen of Innolux ,AUO, Samsung, LG & Sharp.

• Resistive touch panels

• Film touch or glass touch panel options

• Custom touch solutions
